WFI Storage Tank

WFI Storage Tanks are designed and fabricated specifically for storage of Water for Injection (WFI) and Purified Water (PW) in pharmaceutical manufacturing, meeting the strictest regulatory standards.

Key Features

• All welds orbital welded and internally electropolished (Ra ≤ 0.25 µm)
• Passivation as per ASTM A380 / ASTM A967
• 0.2 µm hydrophobic PTFE vent filter with heating jacket
• Nitrogen blanket connection with pressure relief valve
• Full drainability — sloped bottom, no dead legs per ASME BPE
• Insulated jacketed design for maintaining temperature (70°C+ for WFI)
• Conductivity, TOC, temperature, and pressure monitoring provisions

Compliance

European Pharmacopoeia (EP), US Pharmacopoeia (USP), WHO-GMP, 21 CFR Part 11 data recording provisions available.
